DZOFilms
DZOFilm Pictor 20-55mm and 50-125mm T2.8 Super35 Zoom Lens Bundle (PL Mount and EF Mount)
- Brand: DZOFilm
- Model: DZO-7220001B/2 B-BUNDLE
- SKU: A0301A0006G09
- Availability: In Stock
- Option SKU:
- $7,944.78
- Ex Tax: $7,288.79
Professional Cine Lenses with Concrete Build
DZOFILM is devoted to exploring the aesthetic of film and design of optics.
Both mechanics and optics are designed to be compact and versatile,
allowing users to enjoy the smooth and precise operation
and every shooting moment with Pictor Zoom.
Parfocal Design
Center image stay sharp during zooming in or out
No matter from close-up to wide shot,
Or rapidly zoom out to long shot,
Under Parfocal design, focus keeps still all the way along
Minimal Breathing
Thanks to the floating structure, the breathing of Pictor Zoom lenses
are negligible during focusing
Versatile in Ultra Compact
At just 1.6kg (3.5 lbs), Pictor Zoom can be easily mounted on crane, jib, tripod, ROV or other
moving platforms, and provides safer and more efficient work methods by reducing heavy lifting.
Be a better Run-and-Gun Filmmaker, no fear of any complicated scenes or quick shooting. Time saving
without frequent lens changing, Pictor zoom, in no way miss an inspiring moment.
DZOFilm Pictor 20 To 55mm T2.8 Super35 Parfocal Zoom Lens (PL Mount And EF Mount) Specs
Focal Length | 20 to 55mm |
Lens Mount | ARRI PL |
Format | Super35/APS-C |
Image Circle | 31.1 mm |
Maximum T-Stop | T2.8 |
Minimum T-Stop | T22 |
Iris Blades | 16 |
Gear MOD & Pitch | Focus: 0.8 MOD / 32 Pitch Iris: 0.8 MOD / 32 Pitch Zoom: 0.8 MOD / 32 Pitch |
Front Diameter | 95 mm |
Filter Thread | 86 mm |
Focus Scales | Imperial |
Zoom Ratio | 2.75x |
Electronic Communication | No |
Lens Support | Lens Support Foot |
Length | 6.46" / 164 mm |
Weight | 3.35 lb / 1.52 kg |
DZOFilm Pictor 50 To 125mm T2.8 Super35 Parfocal Zoom Lens (PL Mount And EF Mount) Specs
Focal Length | 50 to 125mm |
Lens Mount | ARRI PL |
Format | Super35/APS-C |
Image Circle | 31.1 mm |
Maximum T-Stop | T2.8 |
Minimum T-Stop | T22 |
Iris Blades | 16 |
Gear MOD & Pitch | Focus: 0.8 MOD / 32 Pitch Iris: 0.8 MOD / 32 Pitch Zoom: 0.8 MOD / 32 Pitch |
Front Diameter | 95 mm |
Filter Thread | 86 mm |
Focus Scales | Imperial |
Zoom Ratio | 2.5x |
Electronic Communication | No |
Lens Support | Lens Support Foot |
Length | 6.89" / 175 mm |
Weight | 3.75 lb / 1.7 kg |
